ECHO MAX SERIES 10" Dual 2 Ohm Subwoofer - 1,000 Watts RMS Power Handling (SW10D2)

The SW10D2 is a 10-inch dual 2-ohm subwoofer built around a 3-inch high-temperature voice coil and a composite glass fiber cone, delivering 1000W RMS in a design engineered for thermal management and low distortion. Double-stacked ferrite magnets and an extended pole piece with bumped backplate ventilation keep the motor running clean under sustained high-output conditions. For builds where output and reliability need to coexist, this driver is purpose-built to hold its ground.

• 1000W RMS / 2000W Peak — high power handling through a black-coated 3-inch (76.5mm) voice coil rated for sustained thermal stress
• Dual 2-ohm voice coil — wiring flexibility for series (4Ω) or parallel (1Ω) amplifier configurations
• Aluminum die-cast basket — rigid, resonance-free foundation that preserves cone motion accuracy
• Extended pole piece and bumped backplate — accelerates heat dissipation to reduce power compression
• Composite 3K glass fiber cone with ridge-strengthened surround — supports extensive linear excursion without cone breakup
• Custom copper terminals — accept up to 4 AWG wire for low-resistance, high-current connections
