Wyrestorm | SKU:
EXF10KM5K
Wyrestorm HDMI 2.0 5K HDMI extender | Fiber | 5K60Hz 4:2:0 | 4K60Hz 4:4:4 (EXF10KM5K)
Sold As: EACH
Wyrestorm HDMI 2.0 5K HDMI extender | Fiber | 5K60Hz 4:2:0 | 4K60Hz...
Description
Description
The EXF-10KM-5K Fiber Extender is a high-performance extender based on the SDVoE solution, specifically designed to transmit uncompressed 5120x1440p video and high-fidelity audio up to 10 kilometers (10KM) over a 10G fiber link. Its key advantage is zero end-to-end latency (<120mu s), which is critical for real-time applications, combined with robust support for HDMI 2.0 and HDCP 2.2 standards, including high frame rates (up to 240Hz for 1080p). Built from durable sheet steel with secure screw-lock power connectors, this system ensures professional-grade reliability and pristine signal quality, making it an ideal choice for extending demanding video sources over long distances without any loss in fidelity or speed.
Inputs
TX: 1x HDMI 2.0 (Type-A female)
RX: 1x 10G FIBER (SFP+)
Outputs
TX: 1x 10G FIBER (SFP+)
RX: 1x HDMI 2.0 (Type-A female)
Video Encoding
SDVoE / Non-compression
Audio Formats
LPCM (2.0/5.1/7.1 ch, 44.1/48/96/192 kHz)
Dolby True HD (up to 7.1, 192kHz)
DTS-HD Master (up to 7.1, 192kHz)
Video Resolutions (max)
5120×2160@60Hz (4:2:0), 5120×2160@30Hz (4:4:4), 5120×1440@30Hz (4:4:4), 4096×2160@60Hz (4:4:4), 3840×2160@60Hz (4:4:4)
Supports 1080p up to 240Hz
Supported Standards
HDMI 2.0, HDCP 2.3, HDR10, HDR10+, HLG, Dolby Vision (low latency)
Performance
Zero end to end frame latency (<120μs)
Transmission Distance
10KM
COMMUNICATION & CONTROL
EDID Setting
EDID Passthrough
Firmware Update
AVP Upgrader (Demo Tool) via Ethernet switch
POWER
Power Supply
5V DC 2A
DC Connector
5.5/2.1 DC connector with screw lock
