Wyrestorm | SKU:
EXPSP0102H2
Wyrestorm 4K60Hz 1x2 HDMI Splitter | 4K60Hz 4:4:4 | Dolby Vision & HDR | 4k > 1080p Down-Scaler (EXPSP0102H2)
Sold As: EACH
Wyrestorm 4K60Hz 1x2 HDMI Splitter | 4K60Hz 4:4:4 | Dolby Vision &a...
Description
Description
The latest addition to the WyreStorm Essentials splitter range, the EXP-SP-0102-H2 now offers H2 features and the same value and reliability found in its predecessor, not to mention a few new tricks up its sleeve! Upgrades to support of the full 18Gbps bandwidth HDMI 2.0 offers; 2160p@60Hz 4:4:4 and support for Dolby Vision™ included. As if that wasn’t enough, the EXP-SP-0102-H2 is now featuring a powerful built-in scaler, allowing users to simultaneously connect a mix of 4K and 1080p displays, which gives the source range to play to its fullest potential!
Additional Features
AUDIO & VIDEO
Inputs
1x HDMI In 19-pin HDMI type A
Outputs
2x HDMI Out 19-pin HDMI type A
Audio Formats
2ch PCM | Multichannel: LPCM and Up to DTS-X and Dolby Atmos
Video Resolution (Max)
1920x1080p @60Hz 12bit
1920x1080p @60Hz 16bit
3840x2160p @24Hz 10bit 4:2:0 HDR
3840x2160p @60Hz 8bit 4:4:4
3840x2160p @60Hz 10bit 4:2:0 HDR
4096x2160p @60Hz 8bit 4:2:0
4096x2160p @60Hz 8bit 4:4:4
Supported Standards
DCI | RGB |HDR | HDR10 | Dolby Vision up 30Hz | HLG | BT.2020
Maximum Pixel Clock
600Mhz
COMMUNICATION & CONTROL
HDMI
HDCP 2.2 | EDID | DVI-D supported with adapter (not included)
POWER
Power Supply
5V DC 1A
Max Power Consumption
1.8W
- Allows a transmission from a single HDMI audio/video device to be duplicated and simultaneously distributed to up to two HDMI display devices, such as TV, AVR, digital signage panel or digital projector
- Supports 4K@60Hz 10bit 4:2:0 | 4:4:4 and HDR@24Hz 10bit BT.2020
- Fully HDCP 2.2 compliant
- Data rates up to 18Gbps
- HDR and Dolby Vision support
- Each HDMI output supports scaling down to 1080p
- Automatic input cable equalization for signal regeneration
- DTS-X and Dolby Atmos™ supported
- Plug and play set up for easy installation – no set up/drivers/software required
- Compact, durable design for unobtrusive installation
